Raypak 014325F OEM 1-Try Ignition Control Module for MVB and XTherm “A” Series Commercial Gas Heaters Boilers – Fenwal PIM Replacement Kit
The Raypak 014325F is a factory-direct OEM 1-Try Ignition Control Module (PIM) designed specifically for use with Raypak MVB and XTherm “A” series commercial gas water heaters. This single-try DSI (Direct Spark Ignition) module is part of Raypak’s robust control system, utilizing advanced Fenwal PIM® technology for safe and reliable burner ignition and system management.
This unit serves as the brain of the heater’s ignition system, regulating combustion sequences and safety interlocks. Engineered for performance, this module supports 120VAC ignition circuits and includes an integrated ignition output rated for 5A. It also supports multiple external controls and sensor connections, ensuring compatibility with sophisticated heating system requirements.
014325F Raypak Single-Try 1-Try Ignition Control Module MVB & XTherm “A” Models Key Features:
- OEM Part Number: Raypak 014325F
- Type: Single-Try DSI Ignition Module (1-Try)
- Control Technology: Fenwal PIM® Control with Detect-A-Flame® technology
- Voltage Ratings:
- Ignitor: 120 VAC, 5A
- Input: 24 VAC, 50/60 Hz, 400 mA
- Blower Output: 120/240 VAC, 16A Max
- Boiler/System Pumps: 120/240 VAC, 6-8A Max
- Ambient Temperature Range: -40°F to +165°F
- Compatible Models:
- Raypak MVB “A” Models (2503–4003)
- Raypak XTherm “A” Models (2505–4005)
This ignition module is a direct replacement for failed or outdated PIM assemblies in Raypak’s high-efficiency commercial boilers and water heaters. It supports safety and performance features including:
- Blower and pump sequencing
- Flame sensing and ignition retries
- LED indicators for fault and system diagnostics
- External alarm contacts and remote LED connectivity
Important Installation Notes:
- Installation must be performed by a licensed HVAC or pool heating professional.
- Always disconnect power and gas before servicing.
- Refer to Raypak instruction manual or service bulletins for configuration settings.
This product ensures OEM-grade safety, compatibility, and performance for high-efficiency Raypak commercial heating systems. Ideal for technicians servicing or retrofitting Raypak MVB or XTherm boilers, the 014325F offers a plug-and-play solution backed by Raypak’s renowned engineering standards.
